Product specifications:1X2X22AWG
Conductor material:1/0.64Solid annealed copper conductor
Conductor class: acc. to IEC 60228 standard
Core insulation:PE OD:2.55mm
Core identifier: red and green
Shield:Aluminum - plastic composite tape wrapped, tinned copper wire braided shield
Inner sheath:PVC OD:5.4mm
Outer sheath:PVC OD:8.0mm
Jacket color: PurpleRAL4005
Operating voltage:80V
Conductor resistance:Conform toIEC 60228 clstandard
Electrical data
Damping per unit length
● 9.6 kHz when / Maximum value 0.0025 dB/m
● 38.4 kHz when / Maximum value 0.004 dB/m
● 4 MHz when / Maximum value 0.022 dB/m
● 16 MHz when / Maximum value
0.042 dB/m
Wave resistance
● rating 150 Ω
● 9.6 kHz when 270 Ω
● 38.4 kHz when 185 Ω
● 3 MHz ... 20 MHz when 150 Ω
Relative symmetric tolerance
● 9.6 kHz The wave resistance of time 10 %
● 38.4 kHz The wave resistance of time 10 %
● 3 MHz ... 20 MHz The wave resistance of time 10 %
Circuit resistance per unit length / Maximum value:110 mΩ/m
Shielding resistance per unit length / Maximum value:9.5 Ω/km
Capacitance per unit length / 1 kHz when 28.5 pF/m
Min. bending radius fixed 7.5 x d
Min. bending radius moved 15 x d
Temperature range :-40 °C / +70 °C
Burning behavior:Self-extinguishing, consistentIEC 60332-1standard
