Conductor material: tinned annealed copper wire

Conductor class: superfine stranded, acc.to IEC 60228  cl. 6 pt. 4

Core insulation:ETFE

Core identification:

<18AWG: 5 cores and below are distinguished by color separation, acc. to Din 47100, multi-core cables above 5 cores are distinguished by core wire color separation, and white ink is used for distinction;  ≥18AWG: 5 cores and below are distinguished by color separation, including yellow/ Green ground wire, acc.to Din 47100, multi-core cables with more than 5 cores use black core wires, and white ink numbers are used to distinguish them. (customized upon request if there are special requirements)

Overall stranding: Stranded in layers, back twisted

Shielding: tinned copper wire braided shielding or winding shielding

Outer sheath: PVC

Sheath color: Black (RAL 9005) / green (RAL 6018)

Rated voltage: UL&CUL: 300V, 600V; IEC: 300/300V

Testing voltage: min. 2.0 kV

Minimum bending radius (Fixed): 4 x d

Minimum bending radius (Moved): 7.5 x d < 10 mm  | 10 x d ≥ 10 mm | torsion: 10 x d

Speed:Self-support: maximum.10 m/s, Slide: Max.5 m/s

Torque: Maximum 180°/m

Conductor length: maximum. 50 m

Bending cycle:> 500w | Torque:>300w-180°/m; > 500w- 60°/m

Twist: +/- 180 °/m

Operating temperature (Fixed): -40℃/ +105℃

Operating temperature (Moved): -30℃ / +105℃, torsion: -25℃ / +105℃

Burning behavior: flame retardant IEC60332-1-2,VW-1,FT1

Certification:CE; UL/CUL

Product identification    Aein bei ke®   SHANGHAI  AEIN  WIRE ＆ CABLE  CO.,LTD Model number  specification  voltage FLEXIBLE CONNECTION   OIL RESISTANT ABRASION RESISTANT  CE  Towing chain mark   Meter mark
