Alternative Helukabel Halogen Free Control Cable H05BQ-F / H07BQ-F

Alternative Helukabel Halogen Free Control Cable H05BQ-F / H07BQ-F

These cables can be used for medium mechanical loads in dry, damp or wet environments, e. g. for connecting agricultural and commercial equipment and heaters provided there is no danger of contact with the hot parts or by radiation of heat. These robust and flexible cables are used for electrical tools such as drills and hand-held circulars saws, as well as for portables motors and machinery in agriculture and at building sites, docks and refrigeration plants.


inquiry
  • Product details
Product introduction
  • 01 Product application

        • These cables can be used for medium mechanical loads in dry, damp or wet environments, e. g. for connecting agricultural and commercial equipment and heaters provided there is no danger of contact with hot parts or by radiation of heat. These robust and flexible cables are used for electrical tools such as drills and hand-held circulars saws, as well as for portables motors and machinery in agriculture and at building sites, docks and refrigeration plants.
  • 02 Product characteristics •Abrasion resistant •Notch resistant  and resistant to tearing and cutting
  • 03 Technical certification

    •oil-resistant acc. to DIN VDE 0473-811-404 / DIN EN 60811-404 / IEC 60811-404

    • UV-resistant acc. to DIN EN ISO 4892-2

    •weather-resistant acc. to DIN EN ISO 4892-2

Product structure
Dynamic information

Min. bend radius, flexible

flexible 5 x Outer-Ø

Min. bend radius, fixed

flexible 3 x Outer-Ø

Temperature, flexible

flexible -40°C to +80°C

Temperature, fixed

fixed -50°C to +90°C

Nominal voltage

H05BQ-F U0/U 300/500 V H07BQ-F U0/U 450/750 V

Test voltage core/core

H05BQ-F 2000 V H07BQ-F 2500 V

Cable structure

Conductor

Bare copper conductor, to DIN VDE 0295 cl.5, fine wire, BS 6360 cl.5, IEC 60228 cl.5


Conductor insulation
 Core insulation of rubber compound type EI6 acc. to DIN VDE 0207-363-1 / DIN EN 50363-1

Identification Core identification to DIN VDE 0293-308

Outer jacket Outer sheath of PUR compound type TMPU acc. to DIN EN 50363-10-2

Stranding
Cores stranded with optimal lay lengths


Jacket color

Orange (RAL 2003)


Length marking in meters
