Flat cable for crane door crane YVFBG

Flat cable for crane door crane YVFBG

Crane flat cable YVFBG is used in railcars, carts, transmission machinery, lifting cranes and various related equipment, can also be used for self-proclaimed well or inclined shelf installation, power transmission lines and control, lighting, communication lines.

inquiry
  • Product details
Product introduction
  • 01 Product application


    It is used for the power, control, lighting, communication and other lines of driving, trolley, lifting and other mechanical equipment.


  • 02 Product characteristicsOil resistance, wear resistance
    Tensile and tear resistance
    Resistance to extreme temperatures, softness and bending
Product structure

Conductor: fine stranded oxygen-free bare copper wire, according to VDEO295CLASS 5 or 6

Insulation: weatherproof PVC

Wire core arrangement :≤24 core: one word arrangement, ≥24 core: plum arrangement

Reinforcement: wire rope

Jacket: High quality nitrile mixture

Jacket color: Black (RAL9005) Grey (RAL7001)

Rated voltage: Uo/U 450/750v

Test voltage: 2500V

The temperature rating is fixed :-40℃ to +70℃

Temperature scale shift :-20°C to +70°C

Bending radius: mobile installation: 10xD(cable diameter); Fixed installation: 8xD(cable outer diameter)

Flame retardant class: flame retardant and self-extinguishing (according to part of DIN EN 60332-1-2 VDE 0482 332-1-2:2005-06).

Standard: similar to EN 50525-3-11

Product ID :Aein beike SHANGHAI AEIN WIRE & CABLE CO.,LTD Model Specification Voltage

Product parameter

Keywords: Flat cable for crane door crane YVFBG
