Product introduction
-
01 Product application Low-smoke halogen-free sheathed cables have specified performance in the event of fire and are used for installation in residential, public and industrial buildings. Suitable for applications in dry, wet or wet environments, on, over, in and under stucco,
as well as masonry and concrete walls, but not for embedding in vibrating, compacted or rammed concrete. The cable is also approved for outdoor applications, provided that these applications are not exposed to direct sunlight, and installation of the
cable on the ground or in water is not permitted.
-
02 Product characteristics• Low smoke halogen-free
• No corrosive and toxic gases
• Limited fire spread
• Self-extinguishing flame retardant
-
03 Technical certification • Conform to RoHS
• CE certification = Products comply with EC Low Voltage Directive 2006/95/EG.
Product structure
Conductor material: bare copper wire; Single or multiple stranding
Insulation: halogen-free thermoplastic polymer composite
Insulation color: digital coding core and above can be added yellow-green
Outer sheath: halogen-free thermoplastic polymer composite
Jacket color: Grey (RAL 7035)
Rated voltage :300/500V
Small bending radius for fixed installation :4x outer diameter
Conductor allowable operating temperature +70°C
Halogen-free: According to IEC 60754-2 standard
Flame retardant: According to IEC 60332-1-2 standard
Product identification :Aein beike SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CE meter standard
Product parameter
