Conductor material: bare copper or tinned copper
Conductor class: Conform to UL758 Standard, ASTM B3 or ASTM B33 Standard,DIN VDE 0295 5 Conductor or. IEC 60228 5 Conductor
Core insulation:PVC, HDPE optional
Core identification: 05 mm? 5 cores and below are distinguished by color, in accordance with n. DIN 47100, multi-core cables with more than 5 cores are distinguished by core color, and white ink dots are used for distinction; 205 mm?: 5 cores and below
are distinguished by color, including yellow/green ground wire, in accordance with n. DIN 47100, multi-core cables with more than 5 cores use black core wires and white ink numbers for distinction (customized if special requirements are required)
Shielding layer:Tinned copper braid; Coverage is about 70%
Rated voltage:30V
Stranding:Layered or parallel structure of cores
Outer sheath:PUR
Jacket color:grey RAL 7001, blackRAL9005 Or Green RAL6018
Conductor resistance:UL1581 ASTM Cclass
Minimum bending radius fixed:7.5 x d
Minimum bending radius shift:15 x d
Operating temperature: fixed minimum/Maximum -15 °C / +80 °C
Operating temperature: Moving minimum/Maximum -5 °C / +80 °C
Flame retardant grade: self-extinguishing and flame retardant in accordance with VW-1; FT1; FT2; IEC 60332-1 standards
Certification: UL&CUL: UL1571, UL1589, UL20554 If CE certification or halogen-free requirements are required, please indicate separately
Product identification: Aein bei ke E503807 brother AWM Model number specification temperature voltage cbrother AWM Ⅰ/Ⅱ A/B specification temperature voltage FT2 SHANGHAI
