Conductor material: bare copper or tinned copper
Conductor class: According to UL758, DIN VDE 0295 Class 5 conductor or. IEC 60228 Class 5 conductors
Core cable insulation :PVC, HDPE optional
Core wire identification: 0,5 mm²:5 core and below using color separation, IN line with n.DIN 47100, more than 5 core multi-core cables using core wire color separation, white ink dot distinction; ≥05mm²:5 core and below using color separation, including
yellow/green line, in line with n. DIN 47100, more than 5 core multi-core cable using black core wire, white ink numbered distinction (if there are special requirements on demand)
Stranding: stranding in layers
Outer sheath :PVC
Outer sheath color: gray RAL 7001, black RAL 9005, green RAL 6018
Rated voltage :30V
Test voltage :500V
Conductor resistance :UL1581 ASTM Class C
Small bending radius fixed :7.5 x d
Small bending radius movement :15 x d
Operating temperature fixed minimum/maximum value :-15°C/+80°C
Temperature level shift small/large value :-5°C/+80°C
Flame retardant grade: self-extinguishing and flame retardant in line with VW-1; FT1; FT2; IEC 60332-1 standard
Certification :UL&CUL:UL1571, UL1589, UL2835 If CE certification or halogen-free requirement is required, please specify separately
Product ID :Aein bei ke E503807 AWM Model Specification Temperature Voltage AWM I/II A/B Specification Temperature voltage FT2 SHANGHAI AEIN
