Product introduction
-
01 Product application Flexible low-voltage reel cables are suitable for reel cables that operate under high and very high mechanical stresses in winding, especially with both tensile and torsional stresses and forced direction. It is widely used in port gantry cranes, containercranes, tower cranes and other heavy lifting machinery equipment with similar working conditions, rubbish cranes, slag cranes, ship handling grabs, scavenger grabs and other types of lifting grabs with excellent environmental adaptation performance.
-
02 Product characteristics • Resistance to coolant, microorganism, weak acid and base • PUR Low adhesion of material
-
03 Technical certification • Conform to RoHS• Conform to 2014/35/EU-Guideline (''Low voltage Directive'') CE• We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Structural parameter
Conductor material: Bare copper stranded wire
Conductor class: acc. to DIN VDE 0295 Class 5, refer to IEC 60228 Class 5,GB/T3956 Class 5
Core insulation: PVC-J-105-003 (2105-LF)
Core identification: Up to 5 coloured wires acc. to VDE 0293-308, from 6 black with white numbers and GNYE
Stranding: Stranded in layers
Inner sheath material: DQ PVC-H-90-003(9039-LF)
Anti-twist braid: Polyester braid
Outer sheath:PUR
Jacket color: Black RAL5005; Yellow RAL1023
Rated voltage: 450/750V; 0.6/1 kV
Test voltage: 2.5kV; 3.5kV
Minimum bending radius fixed:10 X D
Minimum bending radius moved: 7.5 X D
Operat. temp. fixed min/max: -40 °C / +80 °C
Operat. temp. moved min/max:-25 °C / +80 °C
Temp. at conductor :+80 °C
Torsion :± 50 °/m
Tensile load: 25N/mm2
Product parameter
