Product introduction
  • 01 Product application
        • Connection and control cable, which is distinguished by its high abrasion resistance and notch-tensile strength properties. Due to its resistance to coolant emulsions, it is suited for use in particularly critical locations in machine, tool and plant construction, rolling mills and steelworks. Suitable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors.

  • 02 Product characteristics• resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater                                                                                                                           • highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion • for outdoor use • The materials used in manufacture are cadmium-free and contain no silicone and free from substances harmful to the wetting properties of lacquers
  • 03 Technical certification

    • oil-resistant acc. to DIN VDE 0473-811-404 / DIN EN 60811-404 / IEC 60811-404                                                  • UV-resistant acc. to DIN EN ISO 4892-2          • weather-resistant acc. to DIN EN ISO 4892-2

Product structure
Cable structure


Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5

Conductor insulation
Oil-resistant PVC in alignment with DIN VDE 0207- 363-3 / DIN EN 50363-3 (compound type TI2), with improved gliding behaviour

Identification Core identification acc. to DIN VDE 0293-334, black cores with consecutive labeling in white digits

Protective conductor starting with 3 cores, G = with protective conductor GN-YE, in the outer layer, x = without protective conductor (OZ)

Cores stranded in layers with optimal lay lengths

Outer jacket Special grade of full polyurethane acc. to DIN VDE 0207-363-10-2 / DIN EN 50363-10-2 (compound type TMPU)

Jacket color

grey (RAL 7001)

Length marking in meters
