Min. bend radius, e-chain® (factor)

12.5 x d

Min. bend radius, e-chain®

2.7 inch (68.8 mm)

Min. bend radius, flexible (factor)

10.0 x d

Min. bend radius, flexible

2.2 inch (55.0 mm)

Min. bend radius, fixed (factor)

7.0 x d

Min. bend radius, fixed

1.5 inch (38.5 mm)

Temperature, e-chain® min.

-4 °F (-20 °C)

Temperature, e-chain® max.

176 °F (80 °C)

Temperature, flexible

-40 °F to +176 °F (-20 °C to +80 °C)

Temperature, fixed

-58°F to +176°F (-50°C to +80°C)

v max., unsupported

10 ft/s (3 m/s)

a. max.

65.6 ft/s² (20 m/s²)

Length of travel

Unsupported up to 33 ft (10 m)

Conductor

Conductor consisting of bare copper wires (according to DIN EN 60228)

Conductor insulation

Mechanically high-quality, PVC mixture

Conductor construction

Cores stranded in optimized pitch

Conductor identification

Cores black with white numerals, one core green-yellow

Unshielded

Yes

Outer jacket

Low adhesion mixture on the basis of iguPUR, adapted to suit the requirements in e-chains®

Jacket color

Jet black (similar to RAL 9005)
