Product introduction
  • 01 Product application
        • Used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use as a connection and control cable in machine tools, assembly lines, conveyor belts, production lines, plant construction, heating and air-conditioning technology, power plants, smelters and steel mills.

  • 02 Product characteristics largely resistant to: oil, for details, see "Technical Information" the materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
  • 03 Technical certification

     flame-retardant acc. to DIN VDE 0482-332-1-2 / DIN EN 60332- 1-2 / IEC 60332-1-2

Product structure
Cable structure


Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5

Conductor insulation
PVC, compound type Z 7225

Identification Core identification acc. to JB/OB colour code, colour coded

Cores stranded in layers with optimal lay lengths

Protective conductor
starting with 3 cores, G = with protective conductor GN-YE, in the outer layer, X = without protective conductor (OB)

Outer jacket PVC acc. to DIN VDE 0207-363-4-1 / DIN EN 50363-4-1 (compound type TM2)

Jacket color

Grey (RAL 7001)

Length marking in meters
