Alternative TKD TML T-RD round Cable

Alternative TKD TML T-RD round Cable

for permanent use in water to connect electrical equipment such as submerged pump motors. Suitable for drinking and industrial water and for medium mechanical requirements.

inquiry
  • Product details
Product introduction
  • 01 Product application for permanent use in water to connect electrical equipment such as submerged pump motors. Suitable for drinking and industrial water and for medium mechanical requirements.
  • 02 Product characteristics•TML T-RD: rated voltage up to 0.6/1 kV when protected and fixed laying in pipes of well systems.•free from lacquer damaging substances and silicone (during production)
    •suitable for permanent use in drinking water up to max. 400 m diving depth
  • 03 Technical certification

    •conform to RoHS •conform to 2014/35/EU-Guideline ("Low-Voltage Directive") CE

     •We are pleased to produce special versions, other dimensions, core and jacket colours on request.

Product structure
Conductor material: Bare copper strand
Conductor class: Acc. to DIN VDE 0295 class 5 resp. IEC 60228 cl. 5
Core insulation: TML T-RD: based on EPR; TML T-F: based on EPR or VPE
Core identification: Acc. to VDE 0293-308 coloured with or without GNYE
Stranding: TML T-RD: cores stranded in layers; TML T-F: cores parallel side by side
Outer sheath: Based on EPR
Sheath colour: Blue
Rated voltage: Uo/U: 450/750 V
Testing voltage: 2,5 kV
Current-carrying-capacity: Acc. to DIN VDE, see Technical Guidelines
Min. bending radius fixed: 4 x d
Min. bending radius moved: 5 x d
Operat. temp. fixed min/max: -40 °C / +60 °C
Operat. temp. moved min/max: -25 °C / +60 °C
Temp. at conductor: +90 °C
Keywords: alternative tkd control cable
