Conductor material: bare copper wire
Conductor class: acc. to IEC 60228 cl. 5standard
Insulation:PVC-J-105-003(2105-LF)
Identification of core wire:< 0,5 mm²:5Core and below the use of color separation, in line withn. DIN 47100.5Multi-core cable above core adopts core separation , white ink dot distinguish; ≥ 0,5 mm²: 5Core and below use color separation, containing
yellow/Green line, matchn. DIN 47100.5Multi-core cable above the core adopts black core wire, white ink numbered to distinguish(If there are special requirements to customize)
Stranding: Stranded in layers
Shielding layer :Tinned copper braid, coverage approx70%
Outer sheath:TPU-H-90-004
Jacket color: BlackRAL9005;greyRAL 7001
Rated voltage:0.5And below300/300V;0.5above300/500V
Test voltage:0.5And below1500V;0.5above2000V
Conductor resistance: Yes IEC 60228 cl. 5standard
Insulation resistance: minimum 20 MΩ x km
Capacitance:core/core about120 nF/km; core/Masking contract160 nF/km
Min. bending radius fixed:12mm The following Ø 5 x d; 20mmThe following Ø 7,5 x d; > 20mm Ø 10 x d
Min. bending radius moved:12mm The followingØ 10 x d; 20mmThe followingØ 15 x d; > 20mm Ø 20 x d
Operat. temp. fixed min/max:-15 ℃ / +80 °C
Operat. temp. moved min/max:-5 ℃ / +80 °C
Burning behavior: class:Self-extinguishing and flame retardant meetIEC 60332-1-2standard
Standard:DIN VDE 0812
Product identification:Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model number specification voltage CE Meter scale
